Four Station Auto PP Fruit Box Making Thermoforming Machine

The DM60 four station full automatic PP Fruit Box thermoforming machines is a high-efficiency and fully automatic plastic sheet pneumatic thermoforming machine that is developed by digesting, absorbing, and innovating similar advanced models at home and abroad.

Model number
DM-60
Weight
14 T
Dimensions
12m*2.8m*2.6m
Suitable material
PP, PS, PET, PVC, OPS, degradable materials, PLA, etc.
Maximum forming area
Width 780*Length 600mm
Work efficiency
40 cycles/minute (depending on material thickness)
Warranty
1 year

Product Description

Our DM60 Four Station Fruit Box thermoforming Machine, also known as vacumn Forming Machine, is a versatile device that combines heating, forming, punching, and cutting into one process, making it ideal for producing fruit boxes and other products that require punching. Our machine is priced competitively, making it an excellent investment for businesses of all sizes and budgets. The combination of efficiency, precision, and affordability makes our Four Station Vacuum Forming Machine an excellent choice for companies looking to improve their production processes and reduce costs. Our Fruit Box thermoforming Machine is also user-friendly, with straightforward controls and easy operation, ensuring that even novice users can operate the machine with ease.

In conclusion, our fruit container thermoforming Machine is an excellent investment for businesses looking to streamline their manufacturing processes. With its advanced technology, precise forming, vacuum forming process, and affordable price, it is an excellent choice for businesses of all sizes and industries. Invest in our Four Station Vacuum Forming Machine today and discover the difference it can make to your production processes.

Four Station Auto PP Fruit Box Making Thermoforming Machine

thermoforming machine detail

Advantages

1. High speed: 40 molds/minute (depending on material thickness)

2. Precise molding: The four-station machine offers greater accuracy and precision in mold placement, resulting in superior product quality.

3. Reduced labor: The machine requires less operator intervention, thus reducing the labor costs associated with traditional molding machines.

4. Easy maintenance: The machine is designed for easy maintenance, with fewer parts to replace and less manual work required.

5. Lower energy consumption: The four-station design reduces energy consumption and operating costs, making it a more environmentally-friendly and cost-effective option.

6. Increased automation: The machine is highly automated, with integrated controls and monitoring systems that help to streamline production and minimize errors.

7. Versatile design: The four-station molding machine can be customized to suit specific production requirements, with different mold configurations and options for adding additional workstations as needed.

Application

Four station full automatic Fruit Box vacuum thermoforming machines can be molded with the following materials: polypropylene (PP), polystyrene (PS), polyvinyl chloride (PVC), polyester (PET) and other thermoplastic sheets such as ABS.

Four Station Auto PP Fruit Box Making Thermoforming Machine

Forming machine Product

Assembly

this is forming+cutting parts made in Honggang factory then deliver to our another two thermoforming machine factories (in Dongguan city)

thermoforming machine Assembly

About Us
1. The original PP Fruit Box Making Thermoforming Machine manufacturer
2. Honggang specializes in forming+ cutting parts for 29 years
3. Honggang provides forming+cutting parts for their 3 stations machine for other vacuum forming manufacturers

Model HG-DM60
Machine Type PP Fruit Box thermoforming machines
Applicable raw materials

PP, PS, PET, PVC, OPS, degradable materials, PLA, etc.

Forming method Positive and negative pressure forming
The maximum forming mold area Width 780×Length 600mm
Minimum molding die area 420×300mm
Air pressure 7 Bar
Travel depth 150 mm
Formed depth 130 mm
Maximum sheet width 450-810mm
Applicable sheet thickness 0.15-2.0mm
Stacking mechanism Hanging point stacking
Rated power of the whole machine 120 KW
Heating power 25-55kw

Weight

14 T

Dimension 12m*2.8m*2.6m
Power access 380V/50HZ (three-phase five-wire)
